Ozone Generator / Sterilizer

Capacity: 15gram to 150gram Function: Ozone sterilizer Application: Pure water/mineral water/drinking water

Quantity:

Introduction

Ozone Equipment is designed & manufactured in-house to provide stable and reliable ozone delivery in high-humidity environments. sensitive electrical equipment fabricated specifically for the harsh environmental conditions found in most industrial water treatment environments.

Our Oxygen Concentrators work on the Pressure Swing Adsorption (PSA) principle, resulting in high purity, ~93% Oxygen feed.

Application :

Function: Ozone Sterilizer
Capacity: 15gram to 150gram
Application: Drinking water/pure water/Mineral water

Technical Data

Product size	5540100
Ozone production (g/h)	50
Ozone concentration (mg/L)	100-120
Ozone power consumption (W)	1100
input power	AC230V/50HZ
Working voltage (KV)	3-7
power frequency	＞3000
Intake flow(L/Min)	7L/min
Intake pressure (MPa)	≤0.2Mpa
Intake temperature (°C)	≤20
Air source dew point (℃)	≤50
cooling method	water cooling
Ozone outlet	10mm quick twist
Use air source	oxygen source
Timing method	0-90 minutes mechanical countdown
working environment conditions	Ambient temperature < 40°C, RH ≤ 85%, it is strictly forbidden to use in flammable and explosive places
machine configuration	Micro-gap discharge ozone tube, high-frequency high-voltage power supply, air compressor pump, cooling fan, control circuit (mechanical timer, working indicator light, air pump switch, ozone switch, etc.)
Main features	1. Automatic work (16 groups of timing switch settings, time error ± 2 seconds/month), which can realize unmanned operation; 2. Manual work (free switch, can be switched on and off at any time, convenient for temporary use or experiment);
