Do You Know How The Filling Machine Works?

Driven by the transmission machinery, all aspects can coordinate the division of labor and truly achieve the effect of linkage. There is a special infrared sensor on the bottle feeding track to receive the induction. When the bottle reaches a certain number, it will automatically jam the following bottle. No bottle, no filling, when the bottle enters the lower position of the filling head, other working sections stop, only the filling head works, when the bottle leaves, the filling head stops working, the track part works, and the bottle stopper is released. The clean bottles from the bottle washing machine are sent to the bottle feeding screw of the filling machine by the bottle conveying belt, and then sent to the bottle supporting cylinder of the rotary table through the bottle feeding star wheel and raised.

Under the guidance of the centering device, the bottle mouth tightly presses the feeding opening of the filling valve to form a seal. After the bottle is evacuated, the back pressure gas (CO,) in the liquid storage tank is flushed into the bottle. When the gas pressure in the bottle is equal to the gas pressure in the liquid storage tank, the liquid valve is opened under the action of the liquid valve spring. . At this time, the object is guided by the umbrella-shaped reflective ring on the return trachea. It is automatically poured into the glass bottle along the bottle wall, and the CO in the glass bottle is replaced by the return pipe to the liquid storage tank. When the object rises to a certain height and closes the mouth of the return trachea. Automatically stop dropping objects. Then close the liquid valve and the gas valve to discharge the pressure gas at the neck of the bottle to prevent the gas-bearing objects from spouting when the glass bottle falls, thus completing the entire filling process.
